Tutorial (Legacy): Site-to-Site Layer 2 Bridging Using Access Server and a Linux Gateway Client
Overview
The diagram above depicts a typical site-to-site layer 2 bridging setup.
This tutorial guides you through setting up a site-to-site layer 2 bridging configuration using Access Server and a Linux gateway client. This setup allows you to bridge two sites transparently, making them appear as part of the same local network.
Two sites: each site connected to the internet with one hosting Access Server and the other hosting an OpenVPN client.
Access Server requirements:
Accessible from the internet with the necessary ports forwarded.
Configured in Layer 2 Ethernet Bridging Mode.
Admin Web UI and console access.
OpenVPN client requirements:
At least two ethernet interfaces (one for internet, one for private LAN).
IP forwarding enabled.
Installed with
bridge-utils,net-tools, andopenvpn.Running a Linux operating system with administrative access.
Ability to upload files and SSH/SFTP access.
Private LAN isolation: The LAN segment should be isolated from other networks.
Sign in to the Admin Web UI.
Click User Management > User Permissions.
Enter a new username for the bridging client.
Check the box Allow Auto-login.
Select Save Settings and Update Running Server.
Your new user is displayed in the list of users.
Click User Profiles.
Find your new user under Username and click New Profile.
Create Profile for [user] pops up.
Select Autologin and click Create Profile.
The .ovpn connection profile downloads.
Download two scripts to your computer:
Use an SFTP client like FileZilla or Cyberduck to upload the two scripts, plus the .ovpn connection profile download to the /etc/openvpn/client/ folder on the Linux OpenVPN client machine.
Connect to your Linux OpenVPN client machine's console and get root privileges.
Rename the profile to use a
.confextension:cd /etc/openvpn/client mv profile.ovpn client.confReplace profile.ovpn with your connection profile's file name.
Ensure
bridge-utilsandnet-toolsare installed:brctl show ifconfig -aIf not installed, use the following command (for Debian/Ubuntu):
apt install bridge-utils apt install net-tools
Use
ifconfig -ato list network interfaces and determine the private interface you want to bridge.Note the interface name (e.g.,
eth2).
Edit
bridge-up.shusing a text editor likenano:nano /etc/openvpn/bridge-up.shChange
eth="eth1"to your identified private interface, e.g.,eth="eth2".Save and exit the file.
Edit the connection profile to include bridging commands:
nano /etc/openvpn/client/client.confAdd the following lines at the top:
up "/bin/bash /etc/openvpn/bridge-up.sh" down "/bin/bash /etc/openvpn/bridge-down.sh" script-security 2 route-nopullRestart the OpenVPN service to apply changes and connect:
systemctl restart openvpn-client@client
Verify the bridge:
ifconfig vpn0The
vpn0interface should display the IP address configured in thebridge-up.shfile. If successful, clients on the bridged site should now obtain an IP address from the remote site via DHCP or manual configuration.
